Adjustable Lock-Tongue Security European Standard Glass Door Electric Strike Plate Lock with Signal

1 / 5

Adjustable Lock-Tongue Security European Standard Glass Door Electric Strike Plate Lock with Signal

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Specifications

Model NO.

NJ-314L-2 glass door electric strike lock

Working Principle

Electronically Controlled Lock

Function

Fail -Safe, Fail-Secure

Shear Strength

1000lbs(500kg)

Operating Voltage

DC 12V

Standby Current

650mA

Face Place Material

High Aluminum

Dimensions

110L*25W*31.5H(mm)

Certification

CE, ROHS, SGS, GMP

Product Description

Ten-Year Lifespan Adjustable Lock-Tongue Security European Standard Electric Strike Lock

NJ-314 is a European standard electric strike lock featuring an adjustable mode for Fail Locked & Fail Unlocked settings. It operates via magnetic force generated by an electromagnetic field for efficient locking and unlocking, including short circuit protection. Built from high-quality aluminum, it offers superior hardness, corrosion resistance, and anti-deformation properties. It is ideal for wooden, metal, and PVC doors.

Technical Functions

Version	Fail-unlocked (Adjustable to Fail-locked style)
Shear Strength	1000Lbs (500kg)
Lock Status Sensors	Optional
Operating Voltage	DC 12V
Surface Temperature	Low Temperature
Ambient Temperature	-10°C - +55°C
Suitable For	European standard Narrow Wooden, Aluminum, Glass, Fireproof & Metal doors
Weight	0.3kg

Packaging & Shipping

Packaging: Neutral Package for safe delivery.
Shipping: Small quantities dispatched within 1-5 work days; large orders within 14 work days post-remittance.

Warranty Policy

Three-year warranty for electromagnetic locks, access control panels, electric bolts, and electric strikes.
One-year warranty for exit buttons, brackets, and power supplies.
Covers non-human factors related to product quality.

Access Control Solutions

Electric Lock Series: Single/Double Electromagnetic Locks, Embedded Series, Electric Bolt Locks, Cabinet Locks, and Door Holders.
Biometric Solutions: Fingerprint Terminals, Face Recognition Attendance, and Access Control Panels.
Guard Tour Systems: Inductive and Wireless Guard Tour Management Devices.
System Accessories: Automatic Swing Door Openers, Exit Switches, Card Readers (RFID/HID), and Magnetic Door Contacts.

Frequently Asked Questions

Q1: Can the lock mode be switched between Fail-Safe and Fail-Secure? Yes, the NJ-314 features an adjustable lock-tongue that allows you to set it to either Fail-Locked or Fail-Unlocked mode as per your security requirements.

Q2: What is the maximum holding force (shear strength) of this strike? This electric strike lock provides a shear strength of 1000lbs, which is approximately 500kg.

Q3: What types of doors are compatible with this European standard lock? It is designed for European standard narrow profiles and is suitable for wooden, aluminum, glass, metal, and fireproof doors.

Q4: Does the product come with any certifications for building safety? Yes, the product is fully compliant with CE and RoHS standards, ensuring it meets international building and safety regulations.

Q5: What is the warranty period for the electric strike lock? We provide a three-year warranty for product quality issues caused by non-human factors.
